Pneumatic Panel in WAG9 locomotive.Almost all the pneumatic functions of the loco are controlled and regulated from this panel.

Date: 2007-12-10
Owner: Khalid Kagzi
Size:
Full size: 1280x960
Last
First •
IMG_0284
Photo Properties
Summary  Details
Make Canon Model Canon PowerShot A710 IS
Aperture Value f/2.8 Color Space Uncalibrated
Flash Red Eye, Auto-Mode Metering Mode Multi-Segment
Shutter Speed Value 1/60 sec Digital Zoom Ratio 1
Date/Time 2007 Dec 10 12:33:16 +0000
Comments
| show full
Solid structure downwards of pic. is compressor (to which black air nozzle is connected) which may be of 1 to 2 HP, thing with 'IMP' written and wires running in it with yellow label tags are solenoid valves, structure with 'AQ 15' in middle of pic. is ...
Posted by Gallery Administrator on 2007 Dec 13 16:37:07 +0000
