Winch turning mechanism driven by steam cylinders and couplings.It seems that no electricity or pneumatics were used to operate this crane with everything big and small being done by steam pressure. (Khalid Kagzi)

Date: 2009-11-14
Owner: Khalid Kagzi
Size:
Full size: 1024x768
Last
First •
Steam driven winch turning mechanism
Photo Properties
Summary  Details
Make Canon Model Canon PowerShot A710 IS
Aperture Value f/2.8 Color Space sRGB
Flash No Flash Metering Mode Multi-Segment
Shutter Speed Value 1/60 sec Digital Zoom Ratio 1
Date/Time 2009 Nov 14 10:49:18 +0000
Comments
| show full
This is very similar to modern earth moving machinary used. Instead of steam, Hydraulic (high pressure oil) is used. The crank shaft would transfer power to worm which would then rotate wheel gear (middle right)rotating the whole assembly over thrust...
Posted by Anant K Singh on 2009 Nov 15 14:09:40 +0000
