This is the key multiplier in WAG9 Locomotive.Its used to unlock the various equipments in the locomotive machine room after duly operating the roof-line earthing switch.

Date: 2007-12-10
Owner: Khalid Kagzi
Size:
Full size: 960x1280
Last
First •
IMG_0286
Photo Properties
Summary  Details
Make Canon Model Canon PowerShot A710 IS
Aperture Value f/2.8 Color Space Uncalibrated
Flash Red Eye, Auto-Mode Metering Mode Multi-Segment
Shutter Speed Value 1/60 sec Digital Zoom Ratio 1
Date/Time 2007 Dec 10 12:34:28 +0000
Comments
i didnt thought that a loco is this much complicated.great set of pics and detailing...would like to know more about the tech aspects...so expecting more from u Khalid sir...
Posted by Deepak Murali on 2007 Dec 11 15:49:12 +0000
Good coverage on technical aspects of WAG9. Similar key interlock is also used in motor-coaches of AC/DC EMUs in Mumbai. http://tinyurl.com/3435l9
Posted by Prakash Tendulkar on 2007 Dec 10 18:07:31 +0000
