Signals, Route Relay Interlocking, Cabins and Equipment

This album contains pictures of various aspects of signalling systems in past and present.

Date: 2003-01-03
Owner: Gallery Administrator
Size: 142 items
First •
Old style block telephone used for communication between adjacent stations of a block section. Sibi-Quetta section, Pakistan, 20
Date: 2011-11-26
Owner: Gallery Administrator
Views: 507
Neale's ball token instruments from Pakistan, 2007
Date: 2011-11-26
Owner: Gallery Administrator
Views: 703
neales-ball-token-instr-dial-2007

A close-up view of the dial of a Neale's ball token block instrument - from Pakistan's Sibi-Quetta section. The makers' plates show that the instrument was made by Saxby and Farmer at their Entally, Kolkata works; the company was a subsidiary of the Londo

Date: 2011-11-26
Owner: Gallery Administrator
Views: 566
Tokenless single line block instrument (UK)

A tokenless single line block instrument of the type widely used in India in the past. This particular example is *not* from India, but from Crag Hall, UK. Photograph from www.tillyweb.biz (signalling...

Date: 2011-11-27
Owner: Gallery Administrator
Views: 1311
akgei-tokenless-block-instrument-2009

Tokenless Block Instrument produced by AKG Electronic Industries.

Date: 2011-12-17
Owner: Gallery Administrator
Views: 1159
abhishek kashyap trainman bareilly

Blast from the near past Phaphamau Juction (NR-LKO).
A sceme that is no more today, as a large Sempahore gantry welcome passengers arriving from Prataphgarh and Raibareily side to enter in City of Sangam- Prayag (Allahabad)
taken in 2012...

Date: 2012-04-21
Owner: Abhishek Kashyap trainman
Views: 1219
dhanbad-diamond

This signal cabin was used to control Dhanbad Diamond Crossing on the now defunct Dhanbad - Pathardih branch line. The crossing was just after the Dhanbad - Chandrapura branch line bifurcation and was clearly visible from this line. Due to the closure of

Date: 2017-06-14
Owner: Gallery Administrator
Views: 2488
