  5. DSC_2738

The ports on the cylinder to the left is exposed to the air box with the piston below the ports probably at the bottom dead center. At this point, the high pressure compressed air in the air box is forced into the cylinder pushing the burnt exhaust gases through the exhaust valves on the cylinder head. The piston on the upstroke will seal the intake ports and start the compression and power cycle of the 2 stroke engine.

Date: 2008-01-18
Size:
Full size: 1280x851
Next • Last • First • Previous
DSC_2738

Photo Properties

Summary  Details
Make NIKON CORPORATION Model NIKON D50
Aperture Value f/4.8 Color Space sRGB
Exposure Bias Value 0 EV Exposure Program Program
Flash No Flash Focal Length 46 mm
Metering Mode Multi-Segment Shutter Speed Value 1/50 sec
Digital Zoom Ratio 1 Date/Time 2008 Jan 18 01:11:45 +0000
