Pneumatic Panel supplied by M/s Faiveley in BHEL WAG-7.The pneumatic panel integrates almost all important pneumatic functions and valves in one assembly with the ducting incorporated in the back plates of the panel.
The red cabinet in the background is the compact Rectifier Block provided in recently produced WAP-4/WAG-7 locomotives. (Khalid Kagzi)

Date: 2014-01-05
Owner: Khalid Kagzi
