Picture showing the invasion of 25000V AC traction in Mumbai as on November 13, 2011. Certainly not to scale. Just tried to show the progress made by CR & WR in bringing 25KV AC traction into Mumbai, ruled by 1500V DC at present. I have modified the layout in the image to ease out the clutteredness. Also, this image shows the entire DC to AC conversion calendar right from 2004 till date.
Note to Moderators: Dear Mods, Please preserve this image as this lists out the entire AC conversion calendar. (Vijay Aravamudhan)

Date: 2011-11-13
Owner: Vijay Aravamudhan
Full size: 1247x826

Wonderful... Great Efforts... Lets hope for the next upgradation happens soon...
Posted by Tushar Dhake on 2011 Nov 15 11:05:32 +0000
Crystal Clear explaination including traction and track layout in & around Bombay! Thanks Vijay.
Posted by Kunal Doddanavar on 2011 Nov 15 02:31:36 +0000
Very nice work! 'Greens invading the Reds' :)
Posted by Sriram SN on 2011 Nov 14 16:32:41 +0000
Good work Vijay...
Posted by Chitrarth Parghi on 2011 Nov 14 15:52:42 +0000
So..... punekars may see 2128 with WAP-4 soon.....
great efforts, Vijay....
Posted by Sagar Badukale on 2011 Nov 14 14:22:49 +0000
| show full
Thanks All,

Dear VSP Garu,
Yes true. We Mumbaikars actually welcome the AC traction wholeheartedly... But then, overall if you see, the huge volume of 25000V territory is slowly invading the very small pocket of 1500V DC territories, ...
Posted by Vijay Aravamudhan on 2011 Nov 14 13:31:46 +0000
Dear Vijay,

##Nice Map.

##But, instead of "Invasion of....", perhaps, you may consider using the words "Welcoming AC Traction into Bombay".

Posted by V. Srinavasa Prasad on 2011 Nov 14 12:58:08 +0000
Great Effort Vijay.
As they say "Ab Dilli er.. Churchgate dur nahin" (neither are WAP 4) :-)
Posted by Anant K Singh on 2011 Nov 14 11:44:29 +0000
Vijay, appreciate your efforts.
Posted by Arzan Kotval on 2011 Nov 14 08:30:58 +0000
