BVI_layout_8_06

Layout of Borivali Station (North end) which shows track layout after mega block on 26th & 27th May 2007. Drawn on MS paint. Akshay Marathe

Date: 2007-06-08

Owner: Gallery Administrator

Size:
Full size: 1200x650

Next •Last

First • Previous

Comments

| show full

Platform 7 & 8 are further south. I have not shown them as the main objective of this diagram was to show the changes at the north end. Note 2 needs a correction. "They are only 3 metres away from oncoming UP trains" should be "They are only 3 metres...

Posted by Akshay Marathe on 2007 Jun 10 14:20:55 +0100

Platform-7 & Platform-8 are not in the vicinity?

Posted by Ranjeet Ramaswamy Iyer on 2007 Jun 09 11:01:33 +0100
